TR-005 Type Helmsman Seat

  • Adjustable backrest and headrest;
  • Seats can be moved back and forth;
  • Folding / angle-adjustable comfortable seat armrest;
  • Seat can rotated 360 degrees, multi-point positioning;
  • Column can be vertically lifting.

TR-005 Type Helmsman Seat

The helmsman seat has been purposely designed with comfort and style to suit helm stations on today’s modern boats. The seat is delivered with a huge array of functions and features, all included at the best price. Genuine leather seats mounted on a shock-absorbing, robust pedestal providing a stable seating experience in all conditions. Each being a high backrest that also serves to protect the head and neck. The seatback angle can also be adjusted from the sitting position. Armrests have a height adjustment feature. YSmarines can offer a wide range of marine helmsman chairs and they are can be customized to meet the different needs of customers.

TR-005 Type Helmsman Seat

Materials Of TR-005 Type Helmsman Seat

1. Slide rail and positioning base uses the high strength aluminum alloy, inside and outside decorative mosaic made of stainless steel;
2.Lifting column with steel, stainless steel synthesis;
3. The seat lifting and tilting, move back and forth, back angle adjusting is used in steel structure;
4. The seat back and the seat cushion adopts the steel inner core and PU cold foam-forming disposable sponge synthesis, outsourcing leather or cloth;
5. Pedal steel plate inner core and environmentally-friendly rubber synthetic;
6. Pneumatic lifting core components pneumatic bar the use of German imports of Stabilus;
7. The chair surface is made of black high-quality PU imitation leather, which can be customized into leather or cloth according to the requirements;
8. Chair shape and color can be customized according to customer requirements;
9. The standard track length of the sliding rail driving chair is 1.2 meters. If it needs to be extended, it can be customized according to the requirements.

 TR-005 Type Helmsman Seat

Functions Of Helmsman Seat

1. The upper part of the seat can be moved back and forth of 120mm, height adjustment 60mm, seat inclination angle range of ±12°;
2.Seat backrest with adjustable angle of 85°-150°, the headrest adjusted up and down 50mm, handrest multi-point positioning control;
3.The seat of pneumatic lifting regulating range 0-150mm
4. The seat can rotate 360°and locked 4-point positioning control;
5. Seat pedal can rotate 90° and regression, upper and lower position adjusting range of 0-50mm;
6.Seat rail slide in 0-5000mm mobile,500mm rail width and depth 28mm ;
7. The seat can bear more than 150FT.LB torsion reached AD grade standard.

Drawings of TR-005 Type Helmsman Seat
Drawings of Drawings of TR-005 Type Helmsman Seat
TR-005 Type Helmsman Seat
TR-005 Type Helmsman Seat

Applications Of Marine Helmsman Seat

Applications Of Marine Helmsman Seat
Applications Of Marine Helmsman Seat

Recommended Transportation Selections Of Marine Helmsman Seat

By Express

By Air Transportation

By Sea Transportation

Suitable for sample order or <50kg goods

Fast 3~10 days

High shipping cost

Door to door service

Suitable for >50kg goods

Fast 3~7days

Lower than the express cost

Airport to airport service

Professional broker needed

Suitable for >300kg goods

Fast 7~45days

Lowest cost

Port to port service

Professional broker needed

Marine Helmsman Seat
Marine Helmsman Seat
Transportation Selections Of Marine Helmsman Seat

FAQ Of YSmarines Helmsman Seat

Q1: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. By the way, The color and material of the chairs also can be customized.
Q2. Do you test all your goods before delivery?
A: Yes, we have a 100% test before delivery.
Q3. How do you make our business long-term and a good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
If you have any questions about the problem, contact us, we will offer the solve way for you.
