CHT4 Type Chart Light for Marine
- Used to light on the chart desk in the steering room, the shell adopts good quality steel, wall type mounting, the light can adjust up and down, left and right, fore and back, equipped with dimmer.
- It adopts an incandescent light illuminant, E27 lamp holder.
- The shell adopts good quality steel.
CHT4 Type Chart Light for Marine
The chart light is used to light on the chart desk in the steering room and can be suitable for boat, yacht, or other marine vessels. It is applicable for the navigation areas of the boat to provide high-quality lighting when inspecting navigation charts and maps. The shell adopts good quality steel, wall type mounting and the light can be adjusted up and down, left and right, fore and back, equipped with dimmer. It can work under the environmental temperature for-30℃~+55℃. YSmarines brings the customers a large selection of top quality marine products and can supply the chart light with highly flexible and fluid in movement.
Production authentication:
1. Conform to GRADE ENTRY NORMS FOR STEEL SHIP.
2. Approved by CCS (CHINA Classification Society)
| Type | CHT4 |
| Voltage | AC 220V |
| Power | ≤100W |
| Illuminate | Incandescent light |
| Lamp holder | E27 |
| Cable outsider diameter | 8mm |
| environmental temperature | -30℃~+55℃ |
| Protection class | IP20 |
| Installation way | Wall type |
| Weight | 2.83KG |
